Hi everybody! Finally a new completed draw from my pile of incompleted works!

I'm taking advantage of this period of illness from job (nothing serious, only back pains...that I'm treating with injections, but don't talk too much about this...) to complete some older works.

Today another Movie vehicle, a Custom '83 GMC Vandura (third generation) from the A-Team TV Series.
There would be a lot to say about this successful TV series, but it's only worth saying that it was one of the flagship series here in Italy in the 80-90s (as well as one of my childhood TV series, along with many others).
Let's talk about the hidden protagonist of the series, namely the Van, which very often helped our heroes to escape from dangerous (and even explosive) situations:

The Chevrolet and GMC G-series vans were made by General Motors for North America. They are in the same vehicle class as the discontinued Ford E series and Dodge Ram van.

The term Chevrolet van also refers to the entire series of vans sold by Chevrolet. The first Chevrolet van was released in 1961 on the Corvair platform, and the latest Chevrolet van in production is the Chevrolet Express.

The G20 and its counterparts replaced the original Chevrolet Corvair Greenbrier Van which was manufactured until 1965. First fielded in the mid-1960s, the model line evolved until it was replaced in 1996 by the Chevrolet Express. 1964-70 G20s came with six-lug wheels (6 lugs - 5.5" (139.6 mm) bolt circle), while the 1971–1995 generation came with the 5 lug - 5" (127 mm) bolt circle.

G20s were fitted with the ball joints from the Chevrolet/GMC ¾- and 1-ton pickups although using the ½ ton pickup's brake rotors.

A light duty version, the G10, was produced alongside the G20—the early versions used the Chevrolet passenger car wheels (5 lugs - 4.75" (120.7 mm) bolt circle) until 1975 (G10s manufactured prior to the 1976 model year had the smaller bolt pattern, common with the short wheelbase vans), yet can still handle LT tire sizes for better handling and stability. The G20 series sported an SB 262 4.3L engine, not much was changed mechanically in the vehicles since their release, other than carburetor to a throttle body injection fuel system, and less use of a vacuum system. Currently there are more after market part options available for its V8 counterparts. Not much has been done in the lines of performance options for the small V6 G20 models, but the reliability remains the same throughout all the G-series models.

The G20's low cost of upkeep, size, and options have made this van popular with all different kinds of trades, from plumbers to caterers.

The third generation GM van was fitted with a variety of engines over its lifetime. A 4.1L (250 CID) straight six was the base engine, this was replaced by the 4.3L V6 in 1985. The 4.3L initially used a four-barrel carburetor; this was updated to TBI fuel injection in 1987. 5.0L and 5.7L small block V8s were the mainstay engines, these were also updated to fuel injection in 1987. A 7.4-liter V8 (230–255 hp (172–190 kW), 385 lb⋅ft (522 N⋅m) at 3600 rpm) was added in 1990, exclusive to the G30. The transmission choices were a three-speed manual, three-speed automatic, four-speed manual, or 4-speed automatic, depending on the model year. Chevrolet also offered, in 1982–1995, the Detroit Diesel V8 engine.

All 1980 vans were given new rear-view mirrors on the driver and passenger doors. Some models got electronic spark control.
Chevrolet offers Bonaventure trim for 1981 and 82 with chrome bumpers, chrome side marker lights and trim around the tail lamps. Also, the only G-series vans that had chrome grille and round headlamps from the factory. Any other G van with a chrome grille from 1978-1982 required the rectangular headlamp option. For 1982, the locking steering column was introduced; the ignition switch, dimmer switch and wiper switch were relocated to the steering column.

After 1982, 3-speed manuals would be relocated to the floor and base models will no longer have round headlamps, which would make Manual Transmission 1982 G vans rare and collectable as 1982 was the only model year with column shift manual transmission and ignition switch on the steering column. Also, 1982 was the only year with the left rear glass as an option on one side only.
The 6.2-litre Diesel was first available and four headlamps, stacked in pairs, were introduced, along with a revised grille. Base models continued with two headlamps. All van models now had rectangular headlamps. From this model year on, tilt steering was available with a manual transmission, because the steering column was retilted to be similar to the C/K trucks and all manual transmission levers wee now on the floor. New steering wheels were introduced as well to be similar to the Monte Carlo/Malibu. Automatic overdrive was introduced. 4-speed manual 117M transmission was introduced. This version was made famous by the American television series The A-Team.

If you want to know more, visit the page https://en.wikipedia.org/wiki/Chevrolet_van (which is also the source of this descriptive part)

Here the historic intro: https://www.youtube.com/watch?v=_MVonyVSQoM

I hope you enjoy the draw, stay tuned for other drawings, bye ;)

EDIT: Instead of the usual white background I wanted to try to create a simple background through editing; later I will try to publish an updated version with the TV series logo
